- Model Number:1079
- Type:integrated circuit, Drive IC
- Place of Origin:Guangdong, China
- Brand Name:Chipskey
- Part number:DC 5V 1-Channel Low Level Trigger Relay Module
- Category:Electronic Module
- Lead Free Status:Lead free / RoHS Compliant
- Condition:Brand New With Original Manufacturer
- Packaging:Reel Tray Tube
- Maximum Operating Temperature:-40°C ~ 125°C
- Warranty:360days
- Dissipation Power:1W-6W
- Supply Voltage:1.5V-6V
DC 5V 1-Channel Low Level Trigger Relay Module
Product description:
1, the module complies with international safety standards, control area load area isolation groove;
2, genuine relay Songle;
3, with the power and relay action instructions, pull bright disconnect does not shine;
4, when a signal in the signal input terminal, the common terminal and the normally start conduction;
5, microcontroller development board can be used as a module that can be used as a home appliance control;
6, the control of the DC or AC signal, can control 220V AC load;
7, there is a normally open and a normally closed contact;
8, blue KF301 terminals to the line of control is more convenient.
High level trigger is a trigger voltage between the signal input and ground can be understood as a way of the signal input terminal and VCC cathode short trigger;
Low trigger means is the voltage between the signal input terminal and the ground for the OV trigger mode can be understood as a way of the signal input terminal and GND negative short trigger
1 relay module wiring
Product Description
- LED indicator light for power on and contacting status indication
- Output terminals are the three screw terminals with blue plastic casing: the terminal in the middle for Com. the left one for NO,the right one for NC
- It can be used as a relay module for various logic control units
- Low level triggering means that when the voltage between the input terminal(IN) and ground(GND) is 0, the relay will be activated.
