AD9850 40MHz DDS Signal Generator Module

• Model Number:23034
• Type:RF/Wireless Development Boards and Kits
• Place of Origin:China
• Certification 1:ROHS
• Certification 2:CE

AD9850 40MHz DDS Signal Generator Module

Product description

Material: durable PCB board and metal.
Dimension (L*W): about 4.5cm x 2.6cm.
Can output 2 sine waves and 2 square waves.
AD9850 frequency range: 0-40MHz.
The after harmonic becomes bigger and bigger when the frequency is between 20-30MHz,and the wave form becomes unclean.
Square Wave: 0-1MHz.
Generated DA reference pins(PIN12)extraction is convenient for the amplitude control application of input wave form. Input voltage can be generated by variable resistance,adjusting the resistance can get different duty ratio square wave.
AD9850 adopts 125MHz active crystal.
Package Including:1 * AD9850 Module DDS Signal Generator Module 0-40MHz 2 Sine Wave and 2 Square Wave Output.
