- Model Number:16g087
- Place of Origin:China
- Brand Name:Chipskey
- Certification 1:ROHS
- Certification 2:CE
- SKU:16g087
Hardware Features
CPU
Cortex ™ -A7 Dual-Core
GPU
Mali400MP2, Complies with OpenGL ES 2.0 / 1.1
RAM
1GB DDR3 (and GPU sharing)
Onboard storage
TF card (maximum 64GB) / MMC card slot can be expanded to 2T SATA hard disk
Onboard Network
10/100/1000 RJ45 Ethernet wifi 802.11 b / g / n
Camera Output
Camera Module CSI-interface
Audio Input
Mic, LINEIN, FMIN
Video output
CVBS, LVDS / RGB, VGA
Audio output
3.5 mm audio port and
power supply
5V DC voltage provided by DC or MicroUSB (OTG)
USB 2.0 Interface
4 USB 2.0 HOST, 1 x USB 2.0 OTG
Push button
Power button
UBoot button
GPIO (2X13) opening
GPIO, UART, I2C bus, SPI bus
CAN bus, PWM, + 3.3v, + 5v, ground
GPIO (2X9) port
GPIO, UART, ADC, RESET, + 3.3v, + 5v, ground.
LED lights
Power Status LED (red)
Ethernet port status LED (blue)
Custom LED lights (green)
remote control
Infrared
Supported operating systems
4.4 Debian Ubuntu RaspberryPi
4.4 Debian Ubuntu Raspbian
Supported Software
Scratch
Scratch
Physical Specifications
Product Size
112 mm × 60mm
Weight
60g
