- Place of Origin:Guangdong, China
- Brand Name:Chipskey
- Type:Drive IC
- Part number:8X8 dot matrix display module kit
- Category:Module
- Lead Free Status:Lead free / RoHS Compliant
- Condition:Brand New With Original Manufacturer
- Packaging:Reel Tray Tube
- Maximum Operating Temperature:-40C ~ 125C
- Warranty:360days
- Operating Temperature:-40C ~ 125C
- Dissipation Power:1W-6W
Matrix LED Driver Platform - Atmeg 328
Full-color RGB dot matrix driver board is a specialized RGB full color dot matrix design an Arduin0 control board module, which in addition to the RGB matrix independently driven , but also can be used as an Arduin0 control board to use. Very convenient and practical , on-board chip is ATmeg 328 chip , board above also raises the ISP interface , you can always give 328 chip programmed bootloader. Drawback is that unlike other Arduin0 Development Board board , have no leads to the corresponding I / 0 I come out , but leads to a number of IIC interface and power supply interface .
Product Features
6 color support ;
Support hardware 16MHZ PWM
Without any additional circuitry
Dedicated GPIO and ADC interfaces
Supports hardware URAT and IIC communication
24 -channel constant current channel current up to 100mA per channel
8 -channel constant current source driving current of up to 500mA per channel
Power supply : +5 V to +5.3 V.
Working Current: 300mA.
Operating temperature range : -10 °C ~ +50 °C
Hardware Features
Support for multiple cascaded without hardware settings.
Supports three RGB color display and mixed colors.
Lattice sequence using planar Cartesian coordinate system , to facilitate understanding .
Support Arduin0 development board powered or external independent power supply.
When multiple cascading is used, if the color is too dark , can improve the power supply voltage to 5.2v or so. Do not exceed 5.4V.
A plurality of cascaded , the data line is always connected to the 1st sub- board. ( Origin ( 0,0 ) where the sub-board for the 1st sub-board )
